Wika - TW15-H-B-M-ND-UD-00100-00045-G1-A-0160-0160-ZZ-ZZ

Manufacturer Wika
Part Number TW15-H-B-M-ND-UD-00100-00045-G1-A-0160-0160-ZZ-ZZ
Inner Code 463876
Description Thermowell TW15, one-piece for screwing Specifications according data sheet: TW 95.15 Head Style: Hex Form of protective tube: Straight Unit: Metric (mm) Process Thread [P or E]: 1/2 NPT Instrument connection [N]: 1/2 NPT female Installation length [U]: 100 mm Connection length [H]: 45 mm Material protective tube: stainless steel 304 / 304L Bore [B or d1]: 6.6 mm Root diameter [Q]: 16 mm Tip diameter [V or F3]: 16 mm Hole Depth: 138 mm Head diameter [vol or F2]: Hex 27 mm Tip thickness: 6.4 mm
Weight 1

Please contact us to request a price quote for Wika - TW15-H-B-M-ND-UD-00100-00045-G1-A-0160-0160-ZZ-ZZ , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Wika-TW15-H-B-M-ND-UD-00100-00045-G1-A-0160-0160-ZZ-ZZ price
