Wika - MW-XXDS
| Manufacturer | Wika |
|---|---|
| Part Number | MW-XXDS |
| Inner Code | 4590994 |
| Description | SWITCH PRESSURE |
| Technical specification | - 0...1 bar - 1/4 NPT-F - 1/2 -14 NPT-F Diaphragm pressure switch, Stainless steel case measuring elements and wetted materials: Diaphragm AISI 316, 304, Inconel or Hastelloy (Piston AISI 316)/ Process Connection AISI 316L contact version: 2 x SPDT or 1 x DPDT silver contact, hermetically sealed, argon gas filling setting range: 0...1 bar Standard, working range = 0...1 bar, proof pressure 4 bar process connection: 1/4 NPT-F electrical connection: 1/2 -14 NPT-F Enclosure with plate for wall or direct mounting Ingress Protection: IP66 Diaphragm: Stainless Steel AISI 316/O-Ring: FPM/Connection: Stainless steel AISI 316L brand: WIKA Instruments Italia Specifications according to data sheet: PV 31.10 Repeatability of set point: ≤ 1% of span set point definition: Set Point customer-specifically configured, one set point 1xDPDT Approvals / Certificates IECEx-ATEX Ex ia 1. set point: 0,25 bar increasing, 2. set point: 0,25 bar increasing |
Please contact us to request a price quote for Wika - MW-XXDS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
