Wika - 47484729

Manufacturer Wika
Part Number 47484729
Inner Code 4187396
Description pressure switch
Technical specification Overview: PSD-30 ; 0...100 bar gauge; one switching output (PNP) + 4...20 mA @ 15...35 V DC; Accuracy: 1.0% of span Configuration pressure switch: Factory setting G1/2B; Sealing: stainless steel circular connector M12x1, 4-pin U+=1, U-=3, S+=2, SP1=4 Approvals: cULus Specifications according to data sheet: PE 81.67 Details: Electronic Pressure Switch with Display Model PSD-30 Specifications according to data sheet: PE 81.67 Power supply: DC 15...35 Output signal: one switching output (PNP) + 4...20 mA Measuring range: 0...100 bar gauge Process connection: G 1/2 B Sealing: stainless steel Special design for media: none Electrical connection: circular connector M12x1, 4-pin Configuration pressure switch: Factory setting Approvals: cULus Certificates: without pin assignment el. connection: U+=1, U-=3, S+=2, SP1=4

Please contact us to request a price quote for Wika - 47484729, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Wika-47484729 price
