Wika - 14021962

Manufacturer Wika
Part Number 14021962
Inner Code 39671
Custom Code 90262040
Technical specification Bourdon tube pressure gauge 232.50 / 233.50 Liquid filled, stainless steel case Model: 232.50 Features according to technical data sheet: PM 02.02 Measuring system: Stainless steel Filling liquid: Without Diameter: 063 mm Scale range: 0 ... 40 MPa 2nd ladder / special ladder: 2nd ladder bar Process connection: G 1/4 B Position of the attack: Radial Flange / Bracket assembly: 3-hole front flange, polished stainless steel Transparent: Polycarbonate Choke: Acc-Ni-Cr, D 0.3 Hand: Standard Additional ordering information: special case without blow-out and with hole (d = 2mm) at 6 o'clock, CNG approval "E1" Accuracy class: Class 1.6 Overpressure safety: Standard Case material: Aisi 304 1.4301 Acc-Ni-Cr (Standard) Case surface: Unpolished Measuring element material: Acc-Ni-Cr 316 SS measuring system Case filling: Without filling, but prepared Protection degree: IP65 Fluid temperature range: * T: -40 ... + 120 ° C * Permissible ambient temperature: -40 ... +60 ° C Movement: Stainless steel Packaging: Single packaging Standard pressure gauge: International (Europe) Color for 2nd staircase (internal): Red RAL 3020 Manufacturer logo: * WIKA * with serial number Individual text per dial: * 232 * * E1 in circle * * 110R-020256 C * above pointer axis * CLASS 0 / C * * T: -40 ... + 120 ° C * below pointer axis Hand clip on the dial: At zero point
Weight 0.16

Please contact us to request a price quote for Wika - 14021962, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Wika-14021962 price
