WEITKOWITZ - 91100 STILO1, 45kN
| Manufacturer | WEITKOWITZ |
|---|---|
| Part Number | 91100 STILO1, 45kN |
| Inner Code | 3340814 |
| Description | Hydraulic Accupress |
| Technical specification | (Catalogue page p. 154) Electro-hydraulic cordless hand press tool for processing cable lugs and connectors up to 150 mm² Characteristics: - Extremely fast work thanks to the triple axial piston pump - Large processing range up to 150 mm² - Quick release head rotatable by 270° - automatic pressure limitation and monitoring with pressure sensor - Motor shutdown and automatic reverse after completed pressing - Electronic control and monitoring of the pressing process - manual rewind - Saving of all pressings and error messages internal storage - Reading out of all cycles and error messages via USB - no aborted pressing cycles due to ongoing monitoring the remaining battery charge - Controlled motor control to increase the service life of transmission, motor and battery - integrated service management and software updates via USB - Fast tool returns due to high return conveyance volume - Multifunction electronics with sleep mode, maintenance display and battery control - integrated, intelligent electronic module with 2 multifunction Light-emitting diodes (3-color LED) - Mini USB interface for common PC systems for: - Output of compression curves and error messages - Service control - Li-ion battery with charge level indicator: 18V 1.5Ah - Dimensions: 370 x 123 x 80mm - Max. stroke: 16 mm, pressing force: 45 kN, weight including battery: 2.3 kg Area of application: - WM crimping dies for Euro Series 6 - 150 mm² - WM crimping dies for standard series 10 - 150 mm² - Hexagonal crimping inserts for compression cable lugs DIN 46235 and connector DIN 46267 6 - 120 mm² (K5 - K20) - Hexagonal crimping inserts for Al compression cable lugs and connector 10 - 70 mm² (K6 - K18) - Circular press inserts for rounding sector-shaped Al and Cu conductors 10 - 150 mm² - WM crimping dies for cable lugs and connectors for finely stranded conductors 10 f - 120 f mm² - Mandrel crimping inserts for crimp cable lugs DIN 46234 6 - 35 mm² - Crimping dies for insulated crimp cable lugs 10 - 35 mm² - Trapezoidal crimping dies for insulated and uninsulated Ferrules 6 - 50 mm² Scope of delivery: - Hydraulic battery press including battery and charger - Operation manual - Software - USB cable - Cloth bag to hold the tool and the crimping dies |
| Weight | 2.3 |
Please contact us to request a price quote for WEITKOWITZ - 91100 STILO1, 45kN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
