Vogel - DSD3-A0030N-NOA12
| Manufacturer | Vogel |
|---|---|
| Part Number | DSD3-A0030N-NOA12 |
| Inner Code | 4848735 |
| Description | PRESSURE SWITCH |
| Custom Code | 85365019 |
| Technical specification | replaces 176-110-300 replaces DSD1-A0030N-NOA11 Medium: oil and fluid grease (NLGI class: 000, 00, 0) Housing material: galvanised steel Contact type: closer Max. switching voltage: 36 volts DC (0.5 amps) Max. contact load: 18 VA Max. switching frequency: 5 (200) cycles/min. Nominal switching pressure: 3 bar Temperature: -10 to +100°C Connection: M10x1 keg Electrical connection: 6.3 × 0.8 flat plug connection/M3 screw connection Installation position: Arbitrary Protection class, housing: IP 65 Protection class, terminal: IP 00 Membrane: NBR Contact material: silver contacts |
Please contact us to request a price quote for Vogel - DSD3-A0030N-NOA12, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
