Vogel - 289155
| Manufacturer | Vogel |
|---|---|
| Part Number | 289155 |
| Inner Code | 4823523 |
| Description | helical bevel gear |
| Custom Code | 84834023 |
| Technical specification | Gearbox type MKSH Gearbox size 16 Translation i= 16.80 Type 70 Drawing Fa.Vogel 055511 Customer 3395500 Customer documents TGW no. 00153649 Mo flange external size VK190 Centring Ø 180 Bolt circle diameter 215 Motor mount 4xD13.5 for motor shaft Ø 38 for motor shaft length 80 Lubrication type oil lubrication SHC 629 lubricant Synthetic texture Viscosity 150 bottom side E (F) Venting side F Oil sight glass side without oil sight glass Drain/plug page E Locking screw Page D with shrinkable clamping set RLK608/3300nm:A Wedi with protective lip A+B Viton shaft seal A+B+C Wedi von Freudenberg A+B+C Lantern/Adapter C: Lantern Coupling C: for Rotex coupling 35/38 Special feature: Material 1.7225: Hollow shaft Quality/Game Twisting Game max. 10' Nitro-Cell transmission paint -Comb. (150093) matt Color RAL9005/Jet black |
Please contact us to request a price quote for Vogel - 289155, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
