Vickers (Eaton) - 565618 / CV1-16-P-0-5
| Manufacturer | Vickers (Eaton) |
|---|---|
| Part Number | 565618 / CV1-16-P-0-5 |
| Inner Code | 242697 |
| Description | Check Valve |
| Technical specification | PRODUCT SPECIFICATIONS LEAKAGE .3 cc/min SPECIAL FEATURES None INSTALLATION TYPE Screw-in Cartridge PILOT PISTON SEAL No FLOW RATE 151 l/min SIZE 16 OPERATION Direct Acting PRESSURE RATING 210 bar HOUSING No NUMBER OF HOUSING PORTS 2 SEAL TYPE Buna-N CRACKING PRESSURE .344738 bar FLUID COMPATIBILITY All general purpose hydraulic fluids such as: MIL-H-5606, SAE 10, SAE 20 etc. RECOMMENDED FILTRATION LEVEL 18/16/13 CAVITY C-16-2 NUMBER OF VALVE PORTS 2 FUNCTION Check Valve PORT TYPE Cartridge Only STYLE Poppet VALVE MATERIAL Steel OPERATING TEMPERATURE -40°C to +120°C APPLICATION Harvesters, refuse haulers, mobile and industrial applications |
| Weight | 1 |
Please contact us to request a price quote for Vickers (Eaton) - 565618 / CV1-16-P-0-5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
