Vickers (Eaton) - 859160
| Manufacturer | Vickers (Eaton) |
|---|---|
| Part Number | 859160 |
| Inner Code | 4440041 |
| Technical specification | PRODUCT NAME Eaton Vickers DG4V-3 60 Design Directional Control Valves Single Stage CATALOG NUMBER 859160 MODEL CODE DG4V-3-0B-M-U-H7-60 PRODUCT LENGTH/DEPTH 6.14 in PRODUCT HEIGHT 3.42 in PRODUCT WIDTH 1.8 in PRODUCT WEIGHT 3.5 lb WARRANTY Hydraulics Warranty PRODUCT SPECIFICATIONS BUILD ORIENTATION Solenoid at A Port End DIODE None WATTAGE 30 W BODY MATERIAL Gray Iron DESIGN CODE 60 WORKING TEMPERATURE - MIN -20 °C PRESSURE RATING 350 bar REDUCER MODULE No COIL TYPE ISO 4400 mounting BUILD TYPE Spring offset end to center LIGHT No STAGE Single Stage FLUID CLEANLINESS 19/17/14 micron SPOOL MONITOR SWITCH None MANUAL OVERRIDE None SPOOL CENTER CONDITION A Port End SPRING ARRANGEMENT B WORKING TEMPERATURE - MAX 70 °C TANK PORT RATING 207 bar LEAKAGE Standard COIL RATING 24 Volt DC SPECIAL FEATURES None FLOW RATE 80 l/min SIZE D03 SEAL MATERIAL Buna-N ACTUATION IDENTIFICATION Solenoid A VALVE MOUNT TYPE Subplate/manifold mounted FLUID COMPATIBILITY Petroleum Oils FUNCTION Directional Control Valve RESPONSE TIME 28-45 ms ACTUATION TYPE Solenoid Operated PERFORMANCE High Performance APPLICATION Die casting & foundry, Machine tool, Marine/Offshore, Press, Primary metal, paper, Test equipment & simulation, Turbine control (wind, steam, water) ELECTRICAL CONNECTOR ISO 4400 (Din 43650) Connector INTERFACE ISO4401-03 ACTUATOR IDENTIFICATION Flag with Standard Build as Per ANSI B93 9 |
Please contact us to request a price quote for Vickers (Eaton) - 859160 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
