Vega - VEGABAR 81B81.GXCHA1GJSPX8IMKX
| Manufacturer | Vega |
|---|---|
| Part Number | VEGABAR 81B81.GXCHA1GJSPX8IMKX |
| Inner Code | 4846373 |
| Description | Pressure transmitter |
| Custom Code | 90262020 |
| Technical specification | eID: DE186122467 Pressure transmitter with diaphragm seal Scope The VEGABAR 81 is a pressure transmitter with diaphragm seal for measuring pressure and level. The at VEGABAR 81 pressure release systems adapted to the process guarantee even with highly corrosive and media are called a safe measurement. The simple interconnection of VEGABAR sensors Series 80 as an electronic differential pressure opens up new possibilities for measuring differential pressures. Your benefit - Easy adjustment, as it can be configured in many ways - Safe measurement up to temperatures of 400 °C - Reliable measurement regardless of foam formation and tank installations Unit of measurement for pressure: bar Scope G: Kazakhstan Approval X: for Ex-free areas (including EAC approval) Process connection/CH material: DN80 PN40 flange form B1, EN1092-1/ 316/316L Pressure regulator liquid/ process temperature A: silicone oil/-40... +150°C (PABS<1bar -40... +150°C) Membrane material 1:316L Pressure type G: relative pressure (measurement against atmosphere) Measurement range J: 0... +40.0 bar (0... +4000kPa) Vacuum service: without Accuracy class S: 0.20% Electronics P: two-wire Profibus PA Optional surge protection: without Additional electronics X: without Case 8: single-chamber stainless steel (electropolished) Housing design/Protection class I: compact/IP66/IP67; NEMA 4X Cable entry/connection M: M20x1.5/PA cable screw connection black (ø5-9mm), standard PLICSCOM K display/control module: built-in; with Bluetooth, magnetic pen operation Certificates X: No User manual: RU+KK+EN - Russian + Kazakh + English Number of operating instructions: 4 Measuring point identification plate: stainless steel Linearization: No Enclosed process seal: none Electronic differential pressure: suitable for configuration Pressure transfer fluid used: VE2 Min. process pressure: -1,000 bar Max. process pressure: 40,000 ba |
Please contact us to request a price quote for Vega - VEGABAR 81B81.GXCHA1GJSPX8IMKX, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
