Vega - SG51.XXSGBTPM
| Manufacturer | Vega |
|---|---|
| Part Number | SG51.XXSGBTPM |
| Inner Code | 3356153 |
| Description | Liquid Vibration Limit Switch |
| Custom Code | 90261029 |
| Technical specification | eID: DE55026455 Liquid Vibration Limit Switch Scope The VEGASWING 51 is a universally applicable liquid limit switch with the smallest dimensions. Regardless of the mounting position, it reliably detects the limit level with millimeter precision. The device can be used for full or empty detection, as approved overfill protection or dry-running or pump protection be used in containers and pipelines. The VEGASWING 51 is an economical solution with highest reliability and safety. your benefit - Minimal time and cost due to simple commissioning without media - Product-independent switching point ensures accurate and reliable function - Low maintenance and maintenance costs Admission guideline/ scope : none/worldwide Approval XX: without Ship classification society: without Execution/process temperature S: standard/ -40... +100°C process connection/material GB: thread G¾ PN64, DIN3852-A /316L Electronic T: transistor PNP 9.6... 35 V DC housing P: 316L Electrical connection/protection class M: M12x1/IP67 Switching point: standard Operating Instructions: DE - German Number of operating manuals: 2 Density range adjustment: High sensitivity (from density 0.5 g/cm³) Switching delay in seconds: 0.500 Recommended weld neck (not included) : ESTSG.1GB** Customs tariff number (HS code): 90261029 |
| Weight | 1 |
Please contact us to request a price quote for Vega - SG51.XXSGBTPM, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
