Vega - VEGASWING 51 \ SG51.XXSGATPM
| Manufacturer | Vega |
|---|---|
| Part Number | VEGASWING 51 \ SG51.XXSGATPM |
| Inner Code | 1491245 |
| Description | Vibrating level switch for liquids |
| Custom Code | 90261029 |
| Technical specification | VEGASWING 51 eID: DE21337870 scope VEGASWING 51 is a universally applicable liquid level switch with very small dimensions. Regardless of the mounting position, it detects the limit level reliably and with millimetre accuracy. The device can be used for full or empty reporting, as approved overfill protection or dry running or pump protection can be used in containers and pipes. VEGASWING 51 is an economical solution with highest reliability and safety. Your benefit - Minimal time and money required due to simple commissioning without medium - Accurate and reliable function due to product-independent switching point - Low costs for servicing and maintenance Approval guideline /scope: none/worldwide Approval XX: without Version/process temperature S: standard/-40... +100°C Process connection/GA material: thread G1 PN64, DIN3852-A/316L Electronic T: transistor PNP 9.6... 35V DC Case P: 316L Electrical connection/degree of protection M: M12x1/IP67 Switching point: standard recommended weld-in socket (not included): ESTSG.1GA** Instruction manual: DE - German number of operating manuals: 2 |
| Weight | 0.54 |
Please contact us to request a price quote for Vega - VEGASWING 51 \ SG51.XXSGATPM, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
