Vega - P/N: B81.ACI5G1GTSZXKIMXX, Type: VEGABAR 81
| Manufacturer | Vega |
|---|---|
| Part Number | P/N: B81.ACI5G1GTSZXKIMXX, Type: VEGABAR 81 |
| Inner Code | 4195193 |
| Description | Pressure Transmitter with Diaphrast |
| Custom Code | 90262020 |
| Technical specification | Pressure unit: bar Scope A: Europe Approval C: ATEX II 1G, 1/2G, 2G Ex ia IIC T6 Process Connection/Material I5: Flange DN50 PN40 Form D, DIN2501/316L Pressure Agent Fluid/ Process temperature G: High-temperature oil and cooling element/-10... +300°C (Pabs<1Bar -10... +200°C) Membrane Material 1:316L Pressure type G: Relative pressure (measurement against atmosphere) Measuring range T ፦1... 0.0bar (-100... 0kPa) Vacuum service: without Accuracy class S: 0.20% Electronics Z: 2-wire 4... 20 mA Optional surge protection: without Auxiliary electronics X: without Housing K: Single-chamber plastic Enclosure Type /Degree of Protection I: Compact/IP66/IP67; NEMA 4X Cable entry/Connection M: M20x1.5/Cable gland PA black (ø5-9mm), Standard Display/Control Module PLICSCOM X: without Certificates X: No Instruction manual: DE - German Number of operating instructions: 1 Measuring plate: stainless steel Linearization: No Process seal supplied: without Electronic differential pressure: Configuration not suitable Pressure sealant fluid used: VE32 Min process pressure ፦1,000 bar Max. process pressure: 2,000 bar |
Please contact us to request a price quote for Vega - P/N: B81.ACI5G1GTSZXKIMXX, Type: VEGABAR 81, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
