Vega - MT31.DK1ADMBX
| Manufacturer | Vega |
|---|---|
| Part Number | MT31.DK1ADMBX |
| Inner Code | 4549247 |
| Description | DETECTOR, WITH MOUNTING BRACKET |
| Custom Code | 90301000 |
| Technical specification | MODEL: MINITRAC 31, MEASUREMENT LOOP: OHM-D-A1, REPEATABILITY: ± 0.1 % AT -40 °C TO + 60 °C (-40 °F TO +140 °F), OPERATING VOLTAGE: 20 TO 72 V DC; 20 TO 253 V AC, 50/60 HZ, MAX. POWER CONSUMPTION: 4 W; 6 VA, INPUT TYPE: 4 TO 20 MA PASSIVE, INTERNAL LOAD: 250 Ω, SWITCHING INPUT (OPEN COLLECTOR/ RELAY CONTACT): 10MA/100MA, SWITCHING VOLTAGE: MIN. 10 MV, MAX. 253 V AC, 253 V DC, SWITCHING CURRENT: MIN. 10 ΜA, MAX. 3A AC, 1A DC, BREAKING CAPACITY: MIN. 50 MW, MAX. 750 VA AC, 40 W DC, CURRENT OUTPUT RANGE: 4 TO 20 MA/HART, ACTIVE OR PASSIVE, MAX. LOAD: 500 Ω (300 Ω WITH INTRINSICALLY SAFE IS), TYPE OF OUTPUT: NPN TRANSISTOR OUTPUT (FLOATING), SWITCHING VOLTAGE: < 55 V DC, LOAD CURRENT: < 400 MA, ELECTRONICS: 4 WIRE, 4 TO 20 MA /HART (EX D OUTPUT), PROTECTION CLASS: IP66/IP67, HOUSING: ALUMINIUM DOUBLE CHAMBER, AMBIENT TEMPERATURE: -40 TO 60°C, EX CERTIFICATION: ATEX II 2 (1) G EX D [IA] IIC T6+ II 1D EX TA [IA] IIIC, END ITEM IDENTIFICATION: FOR DENSITY APPLICATIONS, ADDI. INFO. 1: TO BE SUPPLIED WITH MOUNTING BRACKET, BRACKET MODEL: PTB4.AXN, BRACKET MATERIAL: LCS W/POLYESTER POWDER COATING, BRACKET CONFIGURATION: STANDARD GAUGE MOUNTING, HARDWARE STYLE: STANDARD US THREAD, |
Please contact us to request a price quote for Vega - MT31.DK1ADMBX, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
