Vega - B86.IDACAXAGCHXWI1AX
| Manufacturer | Vega |
|---|---|
| Part Number | B86.IDACAXAGCHXWI1AX |
| Inner Code | 4922225 |
| Description | Hanging pressure transmitter with ceramic measuring cell |
| Custom Code | 90261029 |
| Technical specification | Unit of measurement for pressure: bar Scope I: worldwide Approval D: IEC Ex d ia IIC T6 Design/Process temperature A: PE/-20... +60°C support cable Overall length: Please provide length¹ 0.400... 180,000 Process connection/Material CA: Flange NPS 2" Class 150 RF, ASME B16.5/ 316/316L Sensor options X: without Sealing concept/ Measuring cell seal A: Double/ FKM (VP2/A) Process sealing: without Pressure type G: relative pressure (measurement against atmosphere) Measurement range C: 0... +0.4 bar (0... +40kPa) Accuracy class: 0.1% Electronics H: two-wire 4... 20 mA/HART Optional surge protection: without Additional electronics X: without Housing W: stainless steel two-chamber (precision casting) Housing design/ Protection class I: compact/IP66/IP67; NEMA 4X Cable entry/connection 1: M20x1.5/without PLICSCOM A display/control module: built-in Certificates X: No Operating manual: EN - English Number of operating instructions: 1 Linearization: No Measuring cell type: CERTEC - ceramic measuring cell Measuring cell overload resistance factor: 75,000 Electronic differential pressure: suitable configuration Min. process pressure: -0.500 bar Max. process pressure: 17,000 bar |
Please contact us to request a price quote for Vega - B86.IDACAXAGCHXWI1AX, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
