Valco - VM-040.GR.150T.IP44/NO.WPS
| Manufacturer | Valco |
|---|---|
| Part Number | VM-040.GR.150T.IP44/NO.WPS |
| Inner Code | 3779009 |
| Technical specification | Flow Switch compensated 1..200 Cst Type VM-040.GR.150T.IP44/NO.WPS Body material: bronze Process connections 1.1/2" Gas-F Piston sensing element Maximum working pressure 16 bar Max working temperature 90°C Adjustable by means of the calibration graph on board of the instrument Wide calibration scale, graduated: 0..170° mechanical degrees Maximum recommended flow 180 l/min H2O set point 55 l/min. flow rate 80 l/min. oil 320 cst working temperature 40°C Pressure drop at maximum recommended flow 0.25 bar Microswitch SPDT Maximum electrical load: Electrical output: Plug DIN-43650-A - PG9 cable gland Protection class IP4 |
| Weight | 3 |
