Valco - VM-032.GR.100T.IP65/NO
| Manufacturer | Valco |
|---|---|
| Part Number | VM-032.GR.100T.IP65/NO |
| Inner Code | 4860260 |
| Description | Flow switch |
| Technical specification | Compacted flow switch 1,200 Cst Mods. VM-032.GR.100T.IP65/NO Bronze body 1.1/4" Gas-F process connections Piston sensitive element Max working pressure 16 bar Max working temperature 90°C Adjustable calibration range l/min H2O Adjustable by means of the calibration chart on the instrument board Large calibration scale, graduated: 0.. 170 mechanical degrees Maximum recommended flow 120 l/min H2O Pressure loss at maximum recommended flow 0.25 bar Contact NA Electrical output: DIN-43650-A - PG9 connector Degree of protection IP65 nos. cod. 00.0001.0847 |
Please contact us to request a price quote for Valco - VM-032.GR.100T.IP65/NO, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
