Valco - VM-020.GR.040T.IP65/0213.WPS
| Manufacturer | Valco |
|---|---|
| Part Number | VM-020.GR.040T.IP65/0213.WPS |
| Inner Code | 4053785 |
| Description | Flow switch |
| Technical specification | Compensated 1..200 Cst Type VM-020.GR.040T.IP65/0213.WPS Body material: bronze Process connections 3/4" Gas-F Piston sensing element Maximum working pressure bar Max working temperature 90°C Setting range 10 -40 l/min H2O Adjustable by means of the calibration graph on board of the instrument Wide calibration scale, graduated: 0..170° mechanical degrees Maximum recommended flow 40 l/min H2O Pressure drop at maximum recommended flow 0.25 bar Microswitch SPDT Maximum electrical load: Electrical output: Plug DIN-43650-A - PG9 cable gland Protection class IP65 Code 00.0001.0532 |
Please contact us to request a price quote for Valco - VM-020.GR.040T.IP65/0213.WPS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
