Valco - VM-015.GR.006T.IP65/0213.WPS
| Manufacturer | Valco |
|---|---|
| Part Number | VM-015.GR.006T.IP65/0213.WPS |
| Inner Code | 4041711 |
| Description | Flow switch |
| Technical specification | Compensated 1..200 Cst Type VM-015.GR.006T.IP65/0213.WPS Body material: bronze Process connections 1/2" Gas-F Piston sensing element Maximum working pressure bar Max working temperature 90°C Setting range 2 - 6 l/min H2O Adjustable by means of the calibration graph on board of the instrument Wide calibration scale, graduated: 0..170° mechanical degrees Maximum recommended flow 15 l/min H2O Pressure drop at maximum recommended flow 0.25 bar Microswitch SPDT Maximum electrical load: Electrical output: Plug DIN-43650-A - PG9 cable gland Protection class IP65 |
Please contact us to request a price quote for Valco - VM-015.GR.006T.IP65/0213.WPS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
