Valco - UM3K-020.GM.100.IP65/0371
| Manufacturer | Valco |
|---|---|
| Part Number | UM3K-020.GM.100.IP65/0371 |
| Inner Code | 4041716 |
| Description | Flow switch |
| Technical specification | Paddle type Type UM3K-020.GM.100.IP65/0371 Body material: nickel plated brass Process connections 3/4" Gas-F Paddle and mechanism in st. steel material Max working pressure 25 bar Max working temperature 110 ° C Adjustable setting range 7,5 - 10 l/min H2O Maximum recommended flow 40 l/min H2O Pressure drop at maximum recommended flow 0.01 bar Switch head in polycarbonate SPDT microswitch max electrical loads: 250Vac/5A Electrical output: Plug DIN-43650-A - PG9 cable gland Protection class IP65 Code 01.0001.0526 |
Please contact us to request a price quote for Valco - UM3K-020.GM.100.IP65/0371, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
