Valco - S1.B28.3.0077.O-O.25GO.S1LJ.I2.55
| Manufacturer | Valco |
|---|---|
| Part Number | S1.B28.3.0077.O-O.25GO.S1LJ.I2.55 |
| Inner Code | 4310180 |
| Description | oil level sensor |
| Technical specification | Mod. S1.B 28.3.0077.O-O.25 GO.S1LJ.I 2.55 Float type B28 - Spansil material Brass rod 1" Gas-M connection - brass material Max working pressure 20 bar Max working temperature 105°C Total length L0 = 77 mm. Intervention dimensions in mm. and contact situation in the absence of level: L1 = 55 = Type Contact = NC complete with brass calm tube Max electrical load: Type 3 contact = 300VCA/70VA/0.5A - 350Vdc/50W/0.7A Electrical output: Connector type S1 - DIN-43650-A - PG9 IP65 degree of protection our code 00.0002.1374.1 |
Please contact us to request a price quote for Valco - S1.B28.3.0077.O-O.25GO.S1LJ.I2.55, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
