Valco - M2.B45.7.0750.O.25GO.W1L1.C33.710.130 / 00.0002.5199
| Manufacturer | Valco |
|---|---|
| Part Number | M2.B45.7.0750.O.25GO.W1L1.C33.710.130 / 00.0002.5199 |
| Inner Code | 4521195 |
| Description | level switch |
| Technical specification | Float type B45 - Spansil material Brass rod 1" Gas-M connection - brass material Seal material: NBR Max working pressure 10 bar Max working temperature 105 °C Total length L0 = 750 mm. Intervention rates in mm and contact situations in the absence of level: L1 = 710 = SPDT L2 = 130 = SPDT Contact wiring = common Max electrical load: Contact type 7 = 230VCA/80VA/1A - 230Vcc/60W/1A Electrical output type W1: Die-cast aluminum case with epoxy coating ½” Gas-F cable entry Degree of protection IP65 ns. cod. 00.0002.5199 |
Please contact us to request a price quote for Valco - M2.B45.7.0750.O.25GO.W1L1.C33.710.130 / 00.0002.5199, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
