Valco - FCM6-2,5.15.GO.13PJ
| Manufacturer | Valco |
|---|---|
| Part Number | FCM6-2,5.15.GO.13PJ |
| Inner Code | 3749277 |
| Description | Fixed calibration flow switch |
| Custom Code | 90261029 |
| Technical specification | horizontal or vertical mounting with flow from bottom to top> Brass body 1/2" Gas-M process connections Piston sensitive element Max working pressure 250 bar Max working temperature 90°C Fixed calibration, see available calibrations as per the technical bulletin Maximum recommended flow 25 l/min H2O Pressure loss at the maximum recommended flow rate 0.5 bar Replaceable and replaceable electric head - without removing the flow switch from the pipeline Contact Reed NA Maximum electrical loads: 300VCA-DC/70VA/50W/0.5A Electrical output: Faston 6.3 km Replaceable and replaceable electric head - without removing the flow switch Degree of protection IP00 J= special processing on process attachment 00.0001.0873 |
| Weight | 0.17 |
Please contact us to request a price quote for Valco - FCM6-2,5.15.GO.13PJ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
