Valco - 00.0001.0633.1
| Manufacturer | Valco |
|---|---|
| Part Number | 00.0001.0633.1 |
| Inner Code | 3365387 |
| Description | Fixed calibration flow switch |
| Custom Code | 90261029 |
| Technical specification | Fixed calibration flow switch Mod. FCM5-3.15.GO.12P <horizontal or vertical mounting with flow from Bottom up> Brass body 1/2" Gas-M process connections Piston sensitive element Max working pressure 250 bar Max working temperature 90°C Fixed calibration, see available calibrations as per the technical bulletin Recommended maximum flow rate 25 l/min H2O Pressure loss at maximum recommended flow rate 0.5 bar Replaceable and interchangeable electric head - without removing the flow switch From the pipeline Contact Reed NA Maximum electrical loads: 300VCA-DC/70VA/50W/0.5A Electrical output: Faston 6.3 mm Replaceable and interchangeable electric head - without removing the flow switch Degree of protection IP00 |
| Weight | 1 |
