Valco - CR-025.KVS.IP65
| Manufacturer | Valco |
|---|---|
| Part Number | CR-025.KVS.IP65 |
| Inner Code | 4684089 |
| Description | FLOW SWITCH |
| Technical specification | AISI-316 body 1" Gas-M conical process connection UNI 7/1 - DIN 2999 Suitable for mounting intubations DN25... DN200 Stainless steel pallet AISI-316 bellow sealing element Max working pressure 10 bar static/30 bar dynamic Max working temperature 120°C Adjustable calibration range depending on the DN of the pipeline and the Size of the pallet used See technical sheet Pressure loss at maximum recommended flow rate 0.08 bar ABS electrical case PG 13.5 cable entry SPDT microswitch Maximum electrical loads: 250Vca/15A Degree of protection IP65 Ns. cod. 08.0001.0270 |
Please contact us to request a price quote for Valco - CR-025.KVS.IP65, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
