Valco - 00.0001.0673
| Manufacturer | Valco |
|---|---|
| Part Number | 00.0001.0673 |
| Inner Code | 276623 |
| Description | Flow switch |
| Custom Code | 90261029 |
| Technical specification | Mod. FCM5-1.15.GV.12P <vertical mounting - bottom flow upward> Brass body 1/2" Gas-M process connections Piston sensitive element Max working pressure 250 bar Max working temperature 90°C Fixed calibration, see available calibrations as per the bulletin technician Recommended maximum flow rate 25 l/min H2O Pressure loss at maximum recommended flow rate 0.5 bar Replaceable and interchangeable electric head - without removing the flow switch from the pipeline Contact Reed NA Maximum electrical loads: 300VCA-DC/70VA/50W/0.5A Electrical output: Faston 6.3 mm Replaceable and interchangeable electric head - without removing the flow switch Degree of protection IP00 |
| Weight | 0.17 |
Please contact us to request a price quote for Valco - 00.0001.0673, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
