Vaisala - HMT360 3A12BCD2A4B15A10
| Manufacturer | Vaisala |
|---|---|
| Part Number | HMT360 3A12BCD2A4B15A10 |
| Inner Code | 4271677 |
| Description | TEMPERATURE TRANSMITTER |
| Technical specification | • Safe operation of the transmitter in harsh areas. • Intrinsic safety: you can install the complete transmitter in the area of explosion. • Vaisala HUMICAP® sensor offers high precision, excellent long-term stability term. • NIST certificate included. • Factory Mutual (USA). • 2 m cable for the probe. Humidity measurement Measuring range 0 ... 100% RH Precision At +15 ... +25 ° C (59 ... +77 ° F) ± 1.0% RH (0 ... 90% RH) ± 1.7% RH (90 ... 100% RH) At -20 ... +40 ° C (-4 ... +104 ° F) ± (1.0 + 0.008 x reading)% RH At -40 ... +180 ° C (-40 ... +356 ° F) ± (1.5 +0.015 x reading)% RH HUMICAP® 180R Sensor Temperature measurement Measuring range -20 ... +80 ° C (-4 ... +176 ° F) Accuracy + 20 ° C (+ 68 ° F) ± 0.2 ° C (0.36 ° F) Sensor Pt1000 RTD 1/3 Class B IEC 751 Inputs and outputs Operating voltage 12 ... 28 V Analog output 4 ... 20 mA x 2 Environmental operating conditions Probe Equal to measuring range Transmitter -20 ... +60 ° C (-4 ... 140 ° F) Mechanical characteristics Cable length from probe to transmitter 2 m Plastic grid filter with sintered steel mesh Probe material Stainless steel Transmitter Protection Degree IP66 (NEMA 4X) Housing material G-AlSi10Mg (DIN 1725) |
Please contact us to request a price quote for Vaisala - HMT360 3A12BCD2A4B15A10, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
