Vahle - VLF220-2-951H4-63-S-6
| Manufacturer | Vahle |
|---|---|
| Part Number | VLF220-2-951H4-63-S-6 |
| Inner Code | 4805532 |
| Technical specification | A09 ROAD spring cable drum FOR WINDING UP 12.00 M RUBBER HOSE CABLE TYPE: LT-TR-PUR-R-TF-4x6-J-K CROSS SECTION: 4 X 6.00 QMM DIAMETER: 14.80 MM CABLE OUTLET: HORIZONTAL AFTER 1 OR 2 PAGES PULL-OFF DIRECTION: LEFT SLIP RING BODY: 3-PIN + PE, 63 AMP. PROTECTION CLASS: IP 55 DRUM BODY DIMENSIONS: INNER DIAMETER: 220 MM OUTER DIAMETER: 400 MM WINDING WIDTH: 120 MM DISTANCE APPROX. 0.50 M ABOVE LINE TRAY 2-SPRING DRIVE TYPE 951 SURFACE PROTECTION: GALVANIZED OUTGOING LINE END ON THE FLANGE: 1.50 M ORDER ADOPTED: 1 ------ LIST OF LINE LENGTHS ROUTE:,,,,,,,,,,, ,12,00 M + INSTALLATION HEIGHT:,,,,,, 0.50 M + 2 SAFETY COILS:,, 1.38 M + AL IN THE DRUM:,,,, 1.00 M + AL AT FIXED POINT:,,,,, 2.00 M TOTAL:,,,,,,,,,, ,16,88 M |
Please contact us to request a price quote for Vahle - VLF220-2-951H4-63-S-6, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
