United Electric Controls - P/N: J120-193-M201-M550
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | P/N: J120-193-M201-M550 |
| Inner Code | 5054909 |
| Description | Safety pressure switch 120-Series |
| Technical specification | A00010172 Switch point setting: internal Switch point adjustable in the range: 20.0 psi... 500.0 psi/1.4 bar... 34.5 bar Switch point hysteresis: 4.0 psi... 45.0 psi/0.3 bar... 3.1 bar Maximum working pressure: 1500 psi/103.4 bar Maximum overpressure: 2500 psi/172.7 bar Process connection: 1/2" NPT (inner) made of stainless steel 316 Sensor: Welded 316 stainless steel membrane Notes: large 0.72” Orifice for clean-out purposes. NACE MR0175 compliant with M401 option Housing: Die cast aluminum, epoxy powder coated; Gasketed; cover lock; internal set point lock; aluminum nameplate; protection class NEMA4X/IP66 Switch: 1 SPDT Switching capacity: 15A 125/250/480 VAC resistive (default), 2A @ 30 VDC, 1A @ 48 VDC, 0.5A @ 125 VDC Electrical connection: two 3/4" NPT E/C; terminal Block standard options M201: Factory switch point setting of a Switch; specify pressure and rising/falling! M550: oxygen-purified according to ASTM G93, Type I detection, tests 1 to 3 XY630: Distributorcode Dangerous goods for air and sea freight: No |
Please contact us to request a price quote for United Electric Controls - P/N: J120-193-M201-M550, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
