United Electric Controls - Model: J54-610
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | Model: J54-610 |
| Inner Code | 3846172 |
| Description | Pressure Switch, 54 Series |
| Custom Code | 90262020 |
| Technical specification | NEMA 1 enclosure; One SPDT output; internal hex adjustment with no reference dial 303 stainless steel piston and Buna N O-Ring with 1/4” NPT (female) pressure connection (not recommended for gas service since drying of the O-Ring can allow bleeding of the medium into the atmosphere). Adjustable Set Point Range: 75...1000 psi / 5,2...68,9 bar Deadband: 30...150 psi / 2,1...10,3 bar Over Range Pressure: 6000 psi / 413,7 bar Proof Pressure: 10,000 psi / 689,5 bar Enclosure classification: complies with NEMA 1 requirements Electrical Rating: 15A 125/250/480 VAC resistive Enclosure Material: Lexan® black finish Electrical Connection: 7/8” diameter hole Dangerous goods for air or sea freight: No. |
Please contact us to request a price quote for United Electric Controls - Model: J54-610, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
