United Electric Controls - J120-680-M201-1519
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | J120-680-M201-1519 |
| Inner Code | 4906602 |
| Custom Code | 9032200000 |
| Technical specification | A00008612 Safety pressure switch 120-Series Safety pressure switch 120-Series P/N: J120-680-1519-M201 Switch point setting: internal Switch point adjustable in the range: 100.0 psi... 1700.0 psi/6.9 bar... 117.2 bar Switch point hysteresis: 9.0 psi... 40.0 psi/0.60 bar... 2.80 bar Maximum working pressure: 1700 psi/117.20 bar Maximum overpressure: 2500 psi/172.4 bar Process connection: 1/4” NPT (female) made of 316 stainless steel Sensor: 316 stainless steel bellows Notes: Not recommended for rapid or high cycling Pressure changes Housing: Die cast aluminum, epoxy powder coated; Gasketed; cover lock; internal set point lock; aluminum nameplate; protection class NEMA4X/IP66 Switch: 1 SPDT Switching capacity: see options Electrical connection: two 3/4" NPT E/C; terminal Block standard options 1519: Adjustable deadband, 15 amp 480 VAC resistive; adjustment changes rise setting only. If Adjustment of fall setting is required use primary adjustment. Left hand electrical conduction is Permanently sealed (if applicable) M201: Factory Set Single Switch; Specify Increasing or Decreasing pressure and set point XY630: distributor code Customs tariff number: 9032.20.0000 — Pressure Controls Dangerous goods for air and sea freight: No Listed for dual use: No (without guarantee) Country of origin: USA Weight (per piece): approx. 4.5 lbs./approx. 2 kg |
Please contact us to request a price quote for United Electric Controls - J120-680-M201-1519, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
