United Electric Controls - J120-524-M201-QC1
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | J120-524-M201-QC1 |
| Inner Code | 4877739 |
| Description | Safety pressure switch |
| Custom Code | 9032200000 |
| Technical specification | 120 series safety pressure switch United Electric pressure switch Model: J120-524-M201-QC1 Switching point adjustable in the range of: 2.5 to 50 “wc/6.2 to 124.5 mbar Switchpoint hysteresis: 0.1 to 0.8 “wc/0.2 to 2.0 mbar Overpressure-proof up to: 100 psi/6.9 bar Test pressure: 100 psi/6.9 bar Pressure transducer/seal: membrane off Buna-N/O-ring made from Buna-N Process connection: 1/2 “NPT (female) off epoxy-coated aluminum housing: die-cast aluminum; epoxy resin powder coating; gas tight; opening lock; internal adjustment lock of Switching points Protection class: NEMA 4X; IP66 electr. data Switching capacity: 15A at 125/250/480 VAC resistive (standard), 2A at 30 VDC, 1A at 48 VDC, 0.5A at 125 VDC Microswitch as: single-pole changeover (SPDT) Electrical connection: 2 threaded holes 3/4" NPT (inside), terminal block with Standard screw terminals Weight: approx. 2.5 kg options M201: Factory setting of the switching point/ Set at 8" toilet falling QC1: Certificate of Conformity and Discontinue Customs tariff number: 9032.20.0000 - Pressure switch Dangerous goods for air or sea freight: No Country of origin: USA approximate total weight: approx. 3 kg |
Please contact us to request a price quote for United Electric Controls - J120-524-M201-QC1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
