United Electric Controls - A00009294 - J120-190-M400
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | A00009294 - J120-190-M400 |
| Inner Code | 4965029 |
| Description | Safety pressure switch 120-Series |
| Technical specification | Safety pressure switch 120-Series P/N:J120-190-M400 Switch point setting: internal Switch point adjustable in the range: 5.0 psi... 30.0 psi/0.3 bar... 2.1 bar Switch point hysteresis: 1.0 psi... 6.0 psi/0.1 bar... 0.4 bar Maximum working pressure: 1500 psi/103.4 bar Maximum overpressure: 2500 psi/172.4 bar Process connection: 1/2” NPT (female) made of 316 stainless steel Sensor: Welded 316 stainless steel diaphragm Notes: large 0.72” Orifice for clean-out purposes. NACE MR0175 compliant with M401 option Housing: Die cast aluminum, epoxy powder coated; gasketed; cover lock; internal set point lock; aluminum name plate; Protection class NEMA4X/ IP66 Switch: 1 SPDT Switching capacity: 15A 125/250/480 VAC resistive (standard), 2A @ 30 VDC, 1A @ 48 VDC, 0.5A @ 125 VDC Electrical connection: two 3/4" NPT E/C; terminal block standard options M400: SIL2 for 120, 12 and 100 series on standard models. Consult Inside Sales if adding any options. XY630: Distributorcode |
Please contact us to request a price quote for United Electric Controls - A00009294 - J120-190-M400, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
