United Electric Controls - J120-172-1195-M201-M446
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | J120-172-1195-M201-M446 |
| Inner Code | 4694595 |
| Description | Pressure Switches |
| Custom Code | 90262020 |
| Technical specification | Pressure Switches, 120 Series United Electric Pressure Switch Model: J120-172-1195-M201-M446 Adjustable Set Point Range: 1 to 50 "wc / 0,1 to 3,4 bar Deadband: 0.1 to 1.5 "wc / 6,9 to 103,4 mbar Over Range Pressure: 500 psi / 34,5 bar Proof Pressure: 1000 psi / 68,9 bar Pressure Transducer/Sealing: Welded 316L stainless steel diaphragm Pressure Connection: 1/2” NPT (female) Enclosure: Die cast aluminum, epoxy powder coated; gasketed; cover lock; internal set point lock Classification: NEMA 4X / IP66 Switch Output: One SPDT Electrical Rating: 15A 125/250/480 VAC resistive (standard), 2A @ 30 VDC, 1A @ 48 VDC, 0.5A @ 125 VDC Electrical Connection: two 3/4" NPT E/C; terminal block standard Options 1195: Hermetically sealed, DPDT, 11 A @ 250 VAC; set on falling pressure; deadband and minimum set point may increase M201: Factory set single switch; specify increasing or decreasing pressure and set point M446: Stainless steel ID tag & wire attachment; specify text; limited to 2 lines of 25 characters each; |
Please contact us to request a price quote for United Electric Controls - J120-172-1195-M201-M446, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
