United Electric Controls - Model: H117-191
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | Model: H117-191 |
| Inner Code | 4712361 |
| Description | Pressure switch |
| Custom Code | 90262020 |
| Technical specification | Pressure Switch, 117 Series United Electric Pressure Switch Model: H117-191 Adjustable Set Point Range: 10 to 100 psi / 0,7 to 6,9 bar Deadband: 3 to 45 psi / 0,2 to 2,1 bar Over Range Pressure: 1500 psi / 103,4 bar Proof Pressure: 2500 psi / 172,4 bar Pressure Transducer/Sealing: Welded 316 stainless steel diaphragm Pressure Connection: 1/2” NPT (female) Enclosure: Die cast aluminum, epoxy powder coated, gasketed; captive cover screws; anodized aluminum nameplate Classification: Enclosure Type 4X Switch Output: One SPDT hermetically sealed snap action switch; switch may be wired “normally open” or “normally closed” Electrical Rating: 11 A 125/250 VAC resistive; 5 A @ 28 VDC; 1 A @ 48 VDC; 1/2 A @ 125 VDC; switch contacts gold flashed Electrical Connection: 1/2” NPT (female); two 7/8” diameter knockouts |
Please contact us to request a price quote for United Electric Controls - Model: H117-191, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
