United Electric Controls - H100-218
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | H100-218 |
| Inner Code | 3279747 |
| Description | United Electric Pressure Switch |
| Custom Code | 9032200000 |
| Technical specification | Switching point adjustable in the range of: -1... 0 bar Switch point hysteresis: 33.9... 67.7 mbar Test pressure: 2.1 bar overpressure-proof up to: 0.2 bar Process connection: 1/4" NPT (inside) made of brass nickel-plated, model 218 with stainless steel spring Phosphor bronze bellows, soldered housing: die-cast aluminum; epoxy resin powder coating Switch: microswitches as single-pole changers (SPDT) Switching capacity: standard 15A at 125/250/480 VAC and 1A inductive at 24... 30 VDC Electrical connection: 1/2" NPT (inside); 2 pre-punched 7/8" holes |
| Weight | 2.5 |
Please contact us to request a price quote for United Electric Controls - H100-218, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
