United Electric Controls - F120-7BSM201- M446-QC1
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | F120-7BSM201- M446-QC1 |
| Inner Code | 4803376 |
| Description | temperature switch |
| Custom Code | 9032100000 |
| Technical specification | Temperature Switches, 120 Series Type F120 - Bulb and capillary; one SPDT; epoxy coated enclosure; internal adjustment with no reference dial, dual conduits Adjustable Set Point Rang: 0...400 °F / -17.8...204.4 °C Max. Temp.: 450 °F / 232.2 °C Capillary Length: 6ft Stem or Bulb Size/Finish: 3/8 x 3" Temperature Deadband: typically 1% Enclosure: Die cast aluminum, epoxy powder coated; gasketed Eclosure Certification: Certified to enclosure type 4X. Class I, Division 1 product meets enclosure type 7; Class II, Division 1 product meets enclosure type 9. Certified to IP66 requirements Electrical rating: 15A 125/250/480 VAC resistive (standard), 2A @ 30 VDC, 1A @ 48 VDC, 0.5A @ 125 VDC Electrical Connection: 3/4" NPT E/C; terminal block standard Options M201: Factory set one switch / please provide rising/falling temperature! M446: Stainless Steel ID-Tag attached with wire / please provide text (max. 2 lines of 25 characters each) QC1: Calibration Certificate |
Please contact us to request a price quote for United Electric Controls - F120-7BSM201- M446-QC1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
