United Electric Controls - 1XSWLL-K13-M201-QC1
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | 1XSWLL-K13-M201-QC1 |
| Inner Code | 4838200 |
| Description | Pressure switch |
| Technical specification | Differential Pressure – 316L stainless steel wetted parts, welded diaphragm, two 1/4” NPT (male) process connections, piezo-resisitive strain gauge, silicone oil fill Maximum media temperature: -40 to 257°F (-40 to 125°C) K13: Differential Pressure Operating Range: 0...200.0 psid / 0...13,79 bar Maximum Over Range Differential Pressure: 400 psid / 27,6 bar Maximum Working Gauge Pressure: 1500 psig / 103,4 bar Power input/Switch capacity: Maximum Power Ratings / Output Signal: 2-wire 7.8 – 50 VDC discrete input powered @ 0.75 mA Set Point Switch Ratings (SPST): 7.8 – 50 VDC @ 0.1 A IAW Switch Ratings: 7.8 – 50 VDC @ 0.1 A Accuracy: 0.5% of full range span, at room temperature Approved ambient operating temperature range: -40°F to 185°F (-40°C to 85°C) Enclosure and cover: Type 4X/IP66 certified epoxy-coated aluminum alloy 360 with tempered glass window. Electrical Conduit: 3/4” NPT female aluminum casting; 2 openings Set point & deadband: Programmable over the sensor's entire range Options: M201: Factory set one switch / Please provide pressure value(s), deadband and rising, falling or window mode! QC1: Certificate of Conformance / Calibration Certificate |
Please contact us to request a price quote for United Electric Controls - 1XSWLL-K13-M201-QC1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
