United Electric Controls - Model: 12-S-H-S-N-P-0-M201-M540-QC1
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | Model: 12-S-H-S-N-P-0-M201-M540-QC1 |
| Inner Code | 4479687 |
| Description | Safety pressure switch 12 series |
| Technical specification | Adjustable switching point in the range of: 50... 500 psi/3.4... 34.5 bar Switching point hysteresis: 15... 65 psi/1.0... 4.5 bar Test pressure: 10000 psi/ 689.5 bar overpressure resistant up to: 6000 psi/413.7 bar Sensor Type: P, 316 stainless steel piston, process connection 1/4" NPT (inside) made of 316 stainless steel, with Belleville spring washer Housing: code S: 316 stainless steel Switching capacity: code H: 5 A at 125/250 VAC switching outputs: code S: 1-pole microswitch (SPDT), hermetically encapsulated Electrical connection: Code N: 1/2" NPT external with 1.8 m moulded cable tail options M201: factory switch point setting of 1 switching point/ Switching point must be specified when ordering M540: O-ring made of Viton QC1: Inspection, test and setup report for factory Switching point setting approvals Explosion protection: II 2 G Ex d IIC T6 Gb — II 2 D Ex tb IIIC T85°C Db Approval: DEMKO 08 ATEX 0717128X/IECEx UL 14.0072X Explosion protection: Class I, division 1 and 2, groups A, B, C & D Class II, Division 1 and 2, Groups E, F & G Class III Class I, Zone 1, Group IIC Approval: ATEX |
Please contact us to request a price quote for United Electric Controls - Model: 12-S-H-S-N-P-0-M201-M540-QC1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
