Ultra Pompe S.r.l. - PGLG--28VVV----GG--M4-90L (with lantern and coupling)

Manufacturer Ultra Pompe S.r.l.
Part Number PGLG--28VVV----GG--M4-90L (with lantern and coupling)
Inner Code 1225998
Description GL 28 V with lantern and coupling
Technical specification G series gear pump Main body: Cast iron G25 B5 lantern mounting Complete of lantern and coupling (no drive) Displacement 28 cc/rev Mechanical seal: stainless steel/carbon graphite/FPM External lip seal: FPM Gasket: FPM Rotors: Steel 39NiCrMo3 Nitriding process Bearings: steel/PTFE To be coupled to electric motor 1,5 KW 4 Poles B3/B5 230/400-695 50 Hz IP55 IE2 class F 90L Rated speed: 1400 rpm Theoric rated delivery (1 bar, 220 cSt): 49 l/min Design pressure: 30 bar Operating pressure and viscosity limited by motor power Operating pressure: 10 bar Operating viscosity: 100 cst Operating temperature: - °C
Weight 11

Please contact us to request a price quote for Ultra Pompe S.r.l. - PGLG--28VVV----GG--M4-90L (with lantern and coupling) , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Ultra Pompe S.r.l.-PGLG--28VVV----GG--M4-90L (with lantern and coupling) price

More products of Ultra Pompe S.r.l.

  • GEAR PUMP GL-35-VB – 1,5KW 4P

    - Description: Pump with lantern, coupling and drive Electric motor 1,5 Kw 4 Poles B3/B5 90L 400/50- 480/60 Cast Iron Pump Rotation CW Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM Displacement: 35 cc/rev Rated speed: 1400 rpm Theoric delivery: at 1 bar 49 l/min Max. Temperature: --°c Max. Pressure: -- bar Viscosity range: -- cSt

  • GEAR PUMP GL-35-VBS – 1,5KW 4P

    Description: Pump with lantern, coupling and drive Electric motor 1,5 Kw 4 Poles B3/B5 90L 400/50- 480/60 Cast Iron Pump Rotation CCW Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM Displacement: 35 cc/rev Rated speed: 1400 rpm Theoric delivery: 49 l/min at 1 bar Max. Temperature: --°c Max. Pressure: -- bar Viscosity range: -- cSt

  • GEAR PUMP GL-42– 1,1KW 6P

    Pump with lantern, coupling and drive Electric motor 1,1 Kw 6 Poles B3/B5 400/50- 480/60 90L Cast Iron Pump Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM, Displacement: 42 cc/rev Rated speed: 900 rpm Theoric delivery: at 1 bar -220 cSt 37 l/min Max. Temperature: --°c Max. Pressure: 10 bar

  • GEAR PUMP GL-42– 3KW 4P

    Pump with lantern, coupling and drive Electric motor 3 Kw 4 Poles B3/B5 400/50- 480/60 100L Cast Iron Pump Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM Displacement: 42 cc/rev Max. Temperature: --°c Rated speed: 1400 rpm Max. Pressure: -- bar Theoric delivery: at 1 bar 59 l/min Viscosity range: -- cSt

  • GEAR PUMP GL-52-VB – 1,5KW 8P

    Pump with lantern, coupling and drive Electric motor 1,5 Kw 8 Poles B3/B5 400/50- 480/60 112M Cast Iron Pump Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM, Displacement: 52 cc/rev Rated speed: 700 rpm Theoric delivery: at 1 bar -220 cSt 36 l/min Max. Temperature: --°c Max. Pressure: 10 bar

  • GEAR PUMP GL-93-VB – 4KW 4P

    Pump with lantern, coupling and driveElectric motor 4 Kw 4 Poles B3/B5 400/50- 480/60 112MCast Iron PumpInternal safety valveFPM sealing elements.Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM, Displacement: 93 cc/rev Rated speed: 1400 rpm Theoric delivery:at 1 bar - 220 cSt130 l/minMax. Temperature: --°c Max. Pressure: 10 bar

  • GEAR PUMP GL-93-VB – 4KW 4P

    Pump with lantern, coupling and drive Electric motor 4 Kw 4 Poles B3/B5 400/50- 480/60 112M Cast Iron Pump Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM Displacement: 93 cc/rev Max. Temperature: --°c Rated speed: 1400 rpm Max. Pressure: -- bar Theoric delivery: at 1 bar 130 l/min Viscosity range: -- cSt

  • GL 144 V B

    PUMP TYPE: GEAR, DISCHARGE PRESSURE: 10 BAR, DIRECTION OF ROTATION CLOCKWISE WHEN VIEWED FROM MOTOR DRIVE END, APPLICATION: FOR COLD SHEAR LUBRICATION, RM-5

  • GL 144 VB

    pump with lantern and coupling

  • LF 21 B

    Gear pump

  • LF 28 AB

    Gear pump

  • LF10B.

    Q:0.87m3/h P:10bar 1100rpm 0.5kw

  • LF21B.

    Q:1.8m3/h P:10bar 710rpm 0.75kw

  • SL-14-V-WN

    Gear pump with lantern (no coupling, no drive)

  • 24602

    gear pump NMFH 14 Tag NO 8P-105

  • SL-14-V-OH-WN

    GearcPump with lantern (no coupling, no drive)

  • 24601

    gear pump NMFH 14 Tag NO 8P-108

  • SL-28-V-WN

    Gear Pump with lantern (no coupling, no drive)

  • 24606

    gear pump NMFH 28 Tag NO 8P-607B

  • L-14-BS

    Kit mechanical seal + gasket seal
