Ultra Pompe S.r.l. - PGL---52VVVB---GG--------
| Manufacturer | Ultra Pompe S.r.l. |
|---|---|
| Part Number | PGL---52VVVB---GG-------- |
| Inner Code | 2566944 |
| Description | gear pump |
| Technical specification | GL 52 VB G series gear pump Main body: Cast iron G25 Prepared for lantern B5 mounting Pump bareshaft (no lantern, no coupling, no drive) Displacement 52 cc/rev Mechanical seal: stainless steel/carbon graphite/FPM External lip seal: FPM Gasket: FPM Standard safety relief valve installed (oriented for right CW rotation) Rotors: Steel 39NiCrMo3 Nitriding process Bearings: steel/PTFE To be coupled to electric motor - KW - Poles B3/B5 230/400/50 Hz IP55 Ie2 Class F - Rated speed: - rpm Theoric rated delivery (1 bar, 220 cSt): - l/min Design pressure: 30 bar Operating pressure and viscosity limited by motor power Operating pressure: 10 bar Operating viscosity: 100 cst Operating temperature: -10...+40°C |
| Weight | 50 |
Please contact us to request a price quote for Ultra Pompe S.r.l. - PGL---52VVVB---GG-------- , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
