Turck - TL50BLR2B1G2Y1ALS
| Manufacturer | Turck |
|---|---|
| Part Number | TL50BLR2B1G2Y1ALS |
| Inner Code | 766578 |
| Description | LED – Light sign |
| Technical specification | ID No. 3032186 Signal and display data The purpose of using the LED signal light Light beacon function The light color is red flashing blue rotates green is flashing yellow rotates Dimming does not Color properties 1 red, bright, 24 lm Color properties 2 blue, rotating, 16 lm Color properties 3 green, bright, 52 lm Color properties 4 yellow, rotating, 15 lm Sound signaling continuous tone, 94 dB Electrical data Supply voltage 12...30 VDC DC rated operating current ≤ 125 mA Supply voltage 21...27 VAC Rated operating current AC ≤ 100 mA Max. current consumption of one color 125 mA Max. audio current consumption signaling 35mA Input type bipolar PNP / NPN Reaction time typically < 1 ms Mechanical data can be cascaded no Housing Cylindrical housing, TL50BL Dimensions Ø 50 x 196.6 x 196.6 mm Case material plastic, ABS, black Window material polycarbonate, clear Electrical connection cable, 2 m, PVC Number of veins 8 Ambient temperature -20… +50 °C Relative air humidity 0...95% Degree of protection IP67 Tests / certificates CE Certificates, UL Listed |
| Weight | 1 |
Please contact us to request a price quote for Turck - TL50BLR2B1G2Y1ALS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
