Turck - TL50BLB2G2Y2R2ALSCQ
| Manufacturer | Turck |
|---|---|
| Part Number | TL50BLB2G2Y2R2ALSCQ |
| Inner Code | 766571 |
| Description | LED Indicator – Tower Light |
| Technical specification | Type TL50BLB2G2Y2R2ALSCQ ID 3026760 Signal and display data Purpose LED indicator light Function Tower light Light type Blue, flashing Green, flashing Yellow, flashing Red, flashing Dimmable no Features of color 1 Blue, Flashing, 16 lm Features of color 2 Green, Flashing, 52 lm Features of color 3 Yellow, Flashing, 15 lm Features of color 4 Red, Flashing, 24 lm acoustic signal Continuous tone, 94 dB Electrical data Operating voltage 12…30 VDC DC rated operational current ≤ 125 mA Operating voltage 21…27 VAC AC rated operational current ≤ 100 mA Max. current consumption per color 125 mA Max. current consumption of beeper 35 mA Input type Bipolar (PNP/NPN) Response time typical < 1 ms Mechanical data Cascadable No Design Smooth barrel, TL50BL Dimensions Ø 50 x 204.9 x 204.9 mm Housing material Plastic, ABS, Grey Window material Polycarbonate, clear Electrical connection Connector, M12 × 1, PVC Number of cores 8 Ambient temperature -20…+50 °C Relative humidity 0…95 % Protection class IP67 Tests/approvals Approvals CE, UL listed |
| Weight | 1 |
Please contact us to request a price quote for Turck - TL50BLB2G2Y2R2ALSCQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
