Turck - TL50BLB1GYR1ALSQ
| Manufacturer | Turck |
|---|---|
| Part Number | TL50BLB1GYR1ALSQ |
| Inner Code | 766576 |
| Description | LED display - signal tower |
| Technical specification | Type TL50BLB1GYR1ALSQ Ident No. 3031949 signal and display data Intended use LED indicator light Signal tower function Type of light Blue, rotating Green Yellow Red, rotating Dimmable no Characteristics Color 1 Blue, rotating, 16 lm Features Color 2 Green, always on, 52 lm Characteristics Color 3 Yellow, constant on, 15 lm Characteristics Color 4 Red, rotating, 24 lm Audio signal, continuous tone, 94 dB electrical data Operating voltage 12…30 VDC DC rated operational current ≤ 125 mA Operating voltage 21…27 VAC AC rated operational current ≤ 100 mA Max. current consumption per color 125 mA Max. current consumption of signal tone generator 35 mA Input type Bipolar (PNP/NPN) Response time typically < 1 ms mechanical data Cascadable no Design smooth tube, TL50BL Dimensions Ø 50 x 204.9 x 204.9 mm Housing material plastic, ABS, black Window material polycarbonate, clear Electrical connection Connector, M12 x 1, PVC number of cores 8 Ambient temperature -20…+50 °C Relative humidity 0…95% Degree of protection IP67 Tests/Approvals Approvals CE, UL listed |
| Weight | 1 |
Please contact us to request a price quote for Turck - TL50BLB1GYR1ALSQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
