Turck - T30UXDB
| Manufacturer | Turck |
|---|---|
| Part Number | T30UXDB |
| Inner Code | 766313 |
| Description | Ultrasonic sensor |
| Technical specification | ID 3079998 Ultrasonic data Function Proximity switch Range 200…2000 mm Ultrasound frequency 174 kHz Repeatability ≤ ± 1 mm Temperature drift ≤ 0.02 % of full scale/K Edge lengths of the nominal actuator 100 mm Electrical data Operating voltage 10…30 VDC Response time typical < 92 ms Readiness delay ≤ 500 ms Output function NO contact, PNP Switching frequency ≤ 5 Hz Hysteresis ≤ 3 mm Short-circuit protection yes / Cyclic Reverse polarity protection Complete Wire breakage protection yes Mechanical data Design Tube, T30U Radiation direction straight Dimensions Ø 40 x 45 mm Housing material Plastic, PBT Transducer material Plastic, Epoxyd resin and PU foam Electrical connection Cable, 2 m, PVC |
| Weight | 1 |
Please contact us to request a price quote for Turck - T30UXDB, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
