Turck - T30UHNBQ
| Manufacturer | Turck |
|---|---|
| Part Number | T30UHNBQ |
| Inner Code | 766123 |
| Description | Ultrasonic sensor |
| Technical specification | ID 3058807 Ultrasonic data Function Proximity switch Range 300…2000 mm Ultrasound frequency 128 kHz Repeatability ≤ ± 0.75 mm Temperature drift ≤ 0.17 % of full scale/K Electrical data Operating voltage 12…24 VDC Response time typical < 96 ms Output function 2 normally open contact, NPN Switching frequency ≤ 10 Hz Hysteresis ≤ 2.5 mm Mechanical data Design Tube, T30U Radiation direction straight Dimensions Ø 40 x 45 mm Housing material Plastic, PBT Transducer material Plastic, Epoxyd resin and PU foam Electrical connection Connector, M12 × 1, PVC Ambient temperature -20…+70 °C Relative humidity 100 % Protection class IP67 Power-on indication LED Switching state LED, Yellow |
| Weight | 1 |
Please contact us to request a price quote for Turck - T30UHNBQ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
