Turck - SLSCE14-750Q8
| Manufacturer | Turck |
|---|---|
| Part Number | SLSCE14-750Q8 |
| Inner Code | 762623 |
| Description | Personal safety light curtain |
| Custom Code | 85414900000 |
| Technical specification | cascadable transmitter Purchase order number: 3072402 Alternate order number: 72402 connector M12 x 1, 8-pin Can be cascaded up to 4 modules Protection class IP65 Adjustment via DIP switch Operating voltage 24 VDC +‐ 15% Resolution 14 mm Monitoring field height 750 mm Two EZA-MBK-11 mounting brackets are included with each device, and an additional EZA-MBK-12 bracket is included for device lengths of 900 mm or more. Personal protection class: Cat 4, PL e according to EN ISO 13849‐1:2008 Type 4 according to IEC 61496‐1, ‐2 SIL 3 in accordance with IEC 61508 Function: light curtain Design: cuboid Monitoring field height: 750 mm Range: 100... 6000 mm 14 mm optical resolution Number of rays: 100 Light type: IR Cascadable: Yes With muting function: No Restart lock: adjustable Electrical connection: connector, M12 x 1 Case material: Metal, AL, yellow polyester Ambient temperature: 0... +50 °C Protection class IP65 |
| Weight | 1 |
Please contact us to request a price quote for Turck - SLSCE14-750Q8, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
