Turck - SLPMP25-410
| Manufacturer | Turck |
|---|---|
| Part Number | SLPMP25-410 |
| Inner Code | 762591 |
| Description | Safety Light Curtain |
| Custom Code | 85365019900 |
| Technical specification | Emitter/Receiver Pair Integrated Muting Function Order number: 3084530 Alternative order number : 84530 Electrical connection via RDLP‐8 with open end or via DELPE‐8 with male M12 x 1, 8‐pin Protection class IP65 Flat housing without blind zone Adjustments via DIP switch Resolution can be reduced Blanking function Operating voltage: 24 VDC ± 15 % Resolution 25 mm Scan field 410 mm (L1) Mounting bracket included in delivery Function Light screen Design Rectangular Scan field 410 mm Range 0…7000 mm Optical resolution 25 mm Number of beams 21 Light type IR Cascadable No With muting function yes Start/Restart interlock Adjustable Output function 2 x NC (normally closed), 2 × PNP Electrical connection Cable entry for flat connector Housing material Metal, AL, Yellow polyester Ambient temperature 0…+55 °C Protection class IP65 |
| Weight | 1 |
Please contact us to request a price quote for Turck - SLPMP25-410, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
