Turck - SLPE14-970P8
| Manufacturer | Turck |
|---|---|
| Part Number | SLPE14-970P8 |
| Inner Code | 762625 |
| Description | Personal safety light curtain |
| Custom Code | 85414900000 |
| Technical specification | transmitter Purchase order number: 3083545 Alternative order number: 83545 Cable with connector, 300 mm, M12x1, 8-pin Protection class IP65 Flat housing without blind zone Setting the scan code via DIP switch Operating voltage: 24 VDC ± 15% Resolution 14 mm Monitoring field height 970 mm (L1) Personal protection class: Cat 4, PL e according to EN ISO 13849‐1:2008 Type 4 according to IEC 61496‐1, ‐2 SIL 3 in accordance with IEC 61508 Function: light curtain Design: cuboid Monitoring field height 970 mm Range: 100... 7000 mm 14 mm optical resolution Number of rays: 97 Light type: IR Cascadable: No With muting function: No Restart lock: adjustable Electrical connection: cable with connector, M12 x 1 Cable length: 0.30 m Case material: Metal, AL, yellow polyester Ambient temperature: 0... +55 °C Protection class IP65 |
| Weight | 1 |
Please contact us to request a price quote for Turck - SLPE14-970P8, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
