Turck - SLPCE25-1250P8
| Manufacturer | Turck |
|---|---|
| Part Number | SLPCE25-1250P8 |
| Inner Code | 762598 |
| Description | Personal safety light curtain |
| Custom Code | 85414900000 |
| Technical specification | Emitter Cascadable Order number: 3083616 Alternative order number : 83616 Cable with male end M12 × 1, 8-pin, 300 mm Connection to cascadable nodes via DEE2R‐8… Protection class IP65 Flat housing without blind zone Scan code adjustable via DIP switch Operating voltage: 24 VDC ± 15 % Resolution 25 mm Scan field 1250 mm (L1) Personnel safety Cat 4, PL e acc. to EN ISO 13849‐1:2008 Type 4 according to IEC 61496‐1,‐2 SIL 3 to IEC 61508 Function Light screen Design Rectangular Scan field 1250 mm Range 100…7000 mm Optical resolution 25 mm Number of beams 63 Light type IR Cascadable Yes With muting function no Start/Restart interlock Adjustable Electrical connection Cable with connector, M12 × 1 Cable length 300.0 m Housing material Metal, AL, Yellow polyester Ambient temperature 0…+55 °C Protection class IP65 |
| Weight | 1 |
